AGV Battery Solutions for
Automated Guided Vehicles
UltraXel delivers advanced AGV battery solutions that power automated guided vehicles (AGVs), autonomous mobile robots (AMRs), and warehouse systems with unmatched reliability. Built on our wide temperature lithium-ion cells (-40℃ to +85℃), our battery packs ensure continuous performance, long cycle life, and safety in the most demanding environments.
Whether your AGVs operate in cold storage warehouses, high-temperature factories, or 24/7 logistics centers, UltraXel AGV batteries provide the power, durability, and efficiency you need.
Why Choose UltraXel AGV Batteries?
-
Wide temperature performance: Reliable from -40℃ to +85℃
-
Long cycle life: Up to 10,000+ cycles, reducing replacement costs
-
Fast charging: 1–2 hours for minimum downtime
-
Advanced safety: BMS protection against overcharge, over-discharge, over-current, and thermal risks
-
Eco-friendly: Maintenance-free and no hazardous gas emissions
-
OEM/ODM customization: Tailored voltage, capacity, and pack design
Features for AGV Battery
UltraXel AGV lithium batteries are engineered to deliver reliable power, longer service life, and higher efficiency for automated guided vehicles. With advanced cell technology and intelligent battery management, our solutions ensure safe, continuous, and energy-efficient operation in demanding industrial environments.
Fast Charging
Quick recharge, less downtime
Long Life
Up to 10,000+ cycles
Wide Temperature
Reliable from -40℃ to +85℃
Smart Protection
BMS & APP for real-time monitoring
Applications of UltraXel AGV Batteries
ltraXel AGV battery packs deliver reliable, high-performance power, earning trust across logistics, warehousing, and industrial automation.
AGV Forklift Battery
heavy-duty logistics & warehouse operations
AGV Warehouse Robot Battery
24/7 efficiency for smart warehouses
AGV Industrial Battery
reliable power for factory automation
AGV Logistics Battery
long-lasting energy for distribution centers
Traditional Batteries vs. UltraXel Wide Temperature Lithium-ion AGV Batteries
| Feature / Parameter | UltraXel Wide-Temp Battery | Traditional Batteries |
| Operating Temperature | -40℃ ~ +85℃ | -20℃~60℃ |
| Cycle Life | 3,000 – 10,000+ cycles | 300 – 500 cycles |
| Charging Time | 1–2 hours (fast charging) | 6–8 hours |
| Safety | Advanced BMS protection | Li-plating, thermarl run away |
| Cost of Ownership | Higher upfront, lower lifetime cost | Low upfront, high lifetime cost |
Wide Temperature AGV Batteries: The UltraXel Advantage
AGVs face extreme working conditions, from frozen warehouses at -30℃ to scorching outdoor logistics hubs at +80℃. Conventional batteries fail under such conditions, leading to costly downtime.
UltraXel’s wide temperature lithium-ion batteries ensure:
-
Reliable operation in extreme cold & heat： -40℃~85℃
-
Stable performance for 24/7 automated operations
-
Extended service life with reduced maintenance costs
Custom AGV Battery Pack Solutions
UltraXel provides custom-designed AGV battery packs with OEM & ODM support:
- Tailored voltage & capacity configurations
- Integrated BMS and smart monitoring systems
- Ruggedized designs for outdoor & industrial environments
- Engineering expertise from cell to full battery system
AGV Battery Specifications
Customizable, offering diverse solutions for various application scenarios.
*Application: Lantent Mobile Robot (LMR)
Model | Cell Module | Nominal Voltage | Nominal Capacity | Energy | L*W*H | Weight | Discharge Current | Transient Discharge Current | Battery Case |
48V40Ah | 26650Fe/3.2V/4Ah | 48V | 40Ah | 1920Wh | 300x500x85 mm | 22kg | 40A | 80A | Steel |
25.6V60Ah | 26650Fe/3.2V/4Ah | 25.6V | 60Ah | 1536Wh | 230x500x85 mm | 20kg | 60A | 120A | Steel |
25.2V50Ah | 21700/3.6V/5Ah | 25.2V | 50Ah | 1260Wh | 240x200x90 mm | 15kg | 50A | 100A | Steel |
46.8V50Ah | 21700/3.6V/5Ah | 48.6V | 50Ah | 2340Wh | 430x200x80 mm | 25kg | 50A | 100A | Steel |
25.6V100Ah | 40135/3.2V/20Ah | 25.6V | 100Ah | 2560Wh | 350x250x150 mm | 30kg | 100A | 200A | Steel |
*Application: Forklift Mobile Robot (FMR)
Model | Cell Module | Nominal Voltage | Nominal Capacity | Energy | L*W*H | Weight | Discharge Current | Transient Discharge Current | Battery Case |
25.6V80Ah | 26650Fe/3.2V/4Ah | 25.6V | 80Ah | 2048Wh | 320x240x150 mm | 22kg | 80A | 160A | Steel |
25.6V60Ah | 40135/3.2V/20Ah | 25.6V | 60Ah | 1536Wh | 200x350x150 mm | 20kg | 60A | 120A | Steel |
25.2V40Ah | 26650Fe/3.2V/4Ah | 25.6V | 40Ah | 1024Wh | 200x200x140 mm | 18kg | 40A | 80A | Steel |
25.6V105Ah | LF105/3.2V/105Ah | 25.6V | 105Ah | 2688Wh | 345x304x210 mm | 26kg | 100A | 200A | Steel |
*Application: Traction Robot
Model | Cell Module | Nominal Voltage | Nominal Capacity | Energy | L*W*H | Weight | Discharge Current | Transient Discharge Current | Battery Case |
51.2V60Ah | 26650Fe/3.2V/4Ah | 51.2V | 60Ah | 3072Wh | 480x250x150 mm | 35kg | 60A | 120A | Steel |
25.6V80Ah | 26650Fe/3.2V/4Ah | 25.6V | 80Ah | 2048Wh | 320x240x150 mm | 22kg | 80A | 160A | Steel |
25.2V50Ah | 21700/3.6V/5Ah | 25.2V | 50Ah | 1260Wh | 350x120x120 mm | 15kg | 50A | 100A | Steel |
25.6V80Ah | 21700Fe/3.6V/5Ah | 25.6V | 80Ah | 2048Wh | 320x240x150 mm | 22kg | 80A | 160A | Steel |
*Application: Conveyor Mobile Robot (CMR)
Model | Cell Module | Nominal Voltage | Nominal Capacity | Energy | L*W*H | Weight | Discharge Current | Transient Discharge Current | Battery Case |
25.6V304Ah | LF304/3.2V/304Ah | 25.6V | 304Ah | 7782Wh | 655x255x320 mm | 65kg | 250A | 500A | Steel |
25.6V105Ah | LF105/3.2V/105Ah | 25.6V | 1050Ah | 2688Wh | 345x304x210 mm | 26kg | 100A | 200A | Steel |
51.2V210Ah | LF105/3.2V/105Ah | 51.2V | 210Ah | 10752Wh | 740x430x260 mm | 108kg | 200A | 400A | Steel |
51.2V304Ah | LF304/3.2V/304Ah | 51.2V | 304Ah | 15564Wh | 790x435x320 mm | 132kg | 250A | 500A | Steel |
Partner with UltraXel
As a trusted AGV battery manufacturer, UltraXel combines cell technology leadership with pack engineering excellence to deliver reliable power for the future of automation.
Customize AGV Battery Project
UltraXel supports AGV devices with cell selection, custom battery packs and application-based design.
What We Offer
Battery Cell Selection
14500, 18650, 21700 and 32140 options.
Custom Battery Packs
Custom voltage, capacity, BMS and connectors.
Application Matching
Solutions matched to load, temperature and space.
Our Products
• Operating Temp.: -40℃~+85℃
• Key Feature: Low-temperature performance
• Typical Capacity(0.2C): 2900mAh
• Max charge/discharge: 1.4A / 10A
• Operating Temp.: -40℃~+85℃
• Key Feature: Compact long-life LFP platform
• Typical Capacity(0.2C): 500mAh
• Max charge/discharge: 0.48A/2.40A
• Operating Temp.: -40℃~+85℃
• Key Feature: Compact high-capacity design
• Typical Capacity(0.2C): 750mAh
• Max charge/discharge: 0.7A / 3.5A
• Operating Temp.: -40℃~+85℃
• Key Feature: High-temperature standby reliability
• Typical Capacity(0.2C): 2000mAh
• Max charge/discharge: 1.95A / 10A
• Operating Temp.: -40℃~+85℃
• Key Feature: 1500+ cycle life / safer LFP chemistry
• Typical Capacity(0.2C): 1600mAh
• Max charge/discharge: 1.6A / 7.5A
• Operating Temp.: -40℃~+85℃
• Key Feature: Long runtime / high capacity
• Typical Capacity(0.2C): 3200mAh
• Max charge/discharge: 3.2A / 10A
• Operating Temp.: -40℃~+85℃
• Key Feature: 30A High-rate Discharge Cell
• Typical Capacity(0.2C): 3000mAh
• Max charge/discharge: 3A / 30A
